MT TIRE
M866
Wide tread design provide stronger traction and land cross performance. Ribs in the middle keep the tire going straightly; the grips on the rib improve the acceleration performance.
Specifications
- Pattern
- M866
SIZE | P.R | LI/SS | RIM | SW (mm) | OD (mm) | Load Single | Load Dual | PRESSURE (KPA) | ||
KG | LBS | KG | LBS | |||||||
31×10.50R15LT | 6PR | 109Q | 8½J | 268 | 781 | 1,030 | 2,271 | / | / | 350/50 |
33×12.50R15LT | 6PR | 108Q | 10J | 318 | 832 | 1,000 | 2,205 | / | / | 250/35 |
215/75R15LT | 6PR | 100/97Q | 6 J | 216 | 709 | 800 | 1,765 | 730 | 1,610 | 350/50 |
235/75R15LT | 6PR | 104/101Q | 6½J | 235 | 739 | 900 | 1,985 | 825 | 1,820 | 350/50 |
225/75R16LT | 10PR | 115/112Q | 6 J | 223 | 750 | 1,215 | 2,680 | 1,120 | 2,470 | 550/80 |
235/70R16LT | 8PR | 110/107Q | 7 J | 240 | 742 | 1,060 | 2,335 | 975 | 2,150 | 450/65 |
235/85R16LT | 10PR | 120/116Q | 6½J | 235 | 812 | 1,400 | 3,085 | 1,250 | 2,775 | 550/80 |
245/75R16LT | 10PR | 120/116Q | 7 J | 248 | 780 | 1,400 | 3,085 | 1,250 | 2,775 | 550/80 |
265/75R16LT | 10PR | 123/120Q | 7½J | 267 | 810 | 1,550 | 3,415 | 1,400 | 3,085 | 550/80 |
285/75R16LT | 10PR | 126/123Q | 8 J | 286 | 840 | 1,700 | 3,750 | 1,550 | 3,415 | 550/80 |
265/70R17LT | 10PR | 121/118Q | 8 J | 272 | 810 | 1,450 | 3,195 | 1,320 | 2,910 | 550/80 |
285/70R17LT | 8PR | 121/118Q | 8½J | 292 | 838 | 1,450 | 3,195 | 1,320 | 2,910 | 450/65 |
